On logical and physical interpretations of EPN and EPA


My youngest daughter Daphna has finished last week her summer course in the Technion in the framework of the program of "science seeking youth". She studied her first programming course using "Microworlds", a variation of the rather old Logo language, this is of course been translated to lower level language when executes in practice, by this fact is totally transparent to those who program in Microworlds. I am using this analogy since there seems to be some terminology discussion going on recently about the terms EPA and EPN. These terms were introduced in the past by David Luckham, who used them to describe a physical operational view of event processing application. Thus, an EPA is mapped in 1-1 fashion to a software module, and the EPN describes the running software modules and connections among them using physical channels, the first version of the EPTS glossary reflects this view.

However, the way I am using the terms EPN and EPA is slightly different, the physical view is of interest to system administrators, but for the users, designers and developers, the logical view is more relevant, thus I am using these term in a logical way and not a physical way. In order to demonstrate the difference, let's look at the following simple example: There are many patterns that relate to the management of a call center, one of them is the frustrated customer detection: if a gold customer complains three times within a single day (possibly on multiple issues), then a supervisor should call this customer immediately.

However, there is a spectrum of ways that this application can be implemented in reality:
  • It is possible to have a centralized implementation with a single software module that executes all the different functions within this applications, and actually the EPN is internal to this module;
  • On the other extreme we can have a software module implements any single function instance, for example, an agent that detect the frustrated customer pattern for Alice, where a different agent detects the frustrated customer pattern for Bob.
  • Another possibility is a context oriented implementation --- all patterns related to the Alice are processed within a single software module
  • Yet another possibility is a functional partition -- there is a single module for detecting the frustrated customer pattern for all customers
  • There can be also some more combination.
Should the user / system designer / developer care about it and build a different EPN for each variation ? In the past when event processing was hard coded in general purpose programming languages, the logical EPN was also the physical EPN, but one of the gains from using dedicated event processing languages are the ability to abstract the implementation out.
The actual mapping of functions to software modules is left to an optimizer, and can be dynamically changed based on change in the system behavior, load balancing etc.. Actually the paper we presented in DEBS 2009 is part of such an optimization scheme. Thus, the way I am using the term EPA is a single logical function and not necessarily a software module. In the EPIA book we are building our entire concept based on a logical level meta-language that can be translated to various implementations, and even programming styles. As said, there is also an interest in the physical realization of EPN, but it is more of interest to system administrators and implementers of event processing products, but it should be transparent to the user of event processing applications. More on this topic - later.
